APARATURA FOLOSITA





1.    source of entangled photon quED V3.2 High Rates, down conversion (810 nm, 50 mW, single count rate: 50 kHz, coincidence count rate 5 kHz, BBO crystal, 2 coincidence detectors, 2 polarizers)

2.    quED-MI Michelson interferometer, manual version

3.    quED-HBT Hanbury Brown Twiss cuplor on optical fiber,  with ADP module, beam splitter, software

4.    XYR1/M XY Stage with Ø1" Hole, 13 mm Travel, 360° Rotation, Metric Taps

5.    XYZ Translation Stage with Differential Micrometers, M6 Taps,



quED-Bell-aufbau-300x153                MI-aufbau-300x212





6.    quED-HOM consists of two free space lines, each between two ber couplers and one of them variable in length, and one ber coupled beam splitter.





https://www.qutools.com/wp-content/uploads/2017/08/qued_hom_setup-300x103.png
